Pedersen Machine Tools LTD

Pedersen Machine Tools Ltd

Pedersen Milling machines has been produced in Denmark more than 100 years

Pedersen VPU 1150

Table size 1500 x 350 mm
Longitudinal travel (X) 1150 mm
Cross travel (Y) 400 mm
Vertical travel (Z) 500 mm
Spindle taper SK 40 ISO
Spindle speeds 40-1800 rpm
Mainspindle Power 5.5 kw
Motorized cross beam. 70-3600 speeds
Horizontal spindle speeds 40-1800 rpm
Motor power - vertical 4 kw
Motor power - horizontal 7.5 kw
Digital equipment Ex. Mitutoyo - Fagor
Weight: 2500 kg

Pedersen VPU 950

Table size 1300 x 320 mm mm
Longitudinal travel (X) 850 mm
Cross travel (Y) 340 mm
Vertical travel (Z 500 mm
Spindle taper 40 ISO
Spindle speeds 55-1700 rpm
Mainspindle Power 5.5 kw -

Length: 1900 mm, Height: 2000 mm, Width: 2500 mm, Weight: 3200 kg

Pedersen Machine Tools APS is owned by DenTool APS and Metalmaskiner APS

e-mail to Pedersen

Vrøndingvej 2, 8700 Horsens - Denmark

Phone +45 - 55 77 80 49

Phone +45 - 76 25 55 66

e-mail info@pedersen-machines.com

VAT No. DK-40494677
